Harden® Primary Shredder TPH Series-Hydraulic Drive
![Harden® Primary Shredder TPH Series-Hydraulic Drive](https://icdn.tradew.com/file/201803/1572753/jpg/7709248.jpg?x-oss-process=image/resize,m_pad,l_700/quality,Q_90)
![Harden® Primary Shredder TPH Series-Hydraulic Drive](https://icdn.tradew.com/file/201803/1572753/jpg/7709248.jpg?x-oss-process=image/resize,m_pad,l_100/quality,Q_90)
![Harden® Primary Shredder TPH Series-Hydraulic Drive](https://icdn.tradew.com/file/201803/1572753/jpg/7709253.jpg?x-oss-process=image/resize,m_pad,l_100/quality,Q_90)
![Harden® Primary Shredder TPH Series-Hydraulic Drive](https://icdn.tradew.com/file/201803/1572753/jpg/7709258.jpg?x-oss-process=image/resize,m_pad,l_100/quality,Q_90)
![Harden® Primary Shredder TPH Series-Hydraulic Drive](https://icdn.tradew.com/file/201803/1572753/jpg/7709259.jpg?x-oss-process=image/resize,m_pad,l_100/quality,Q_90)
Detail Information
Harden® Primary Shredder TPH Series
![](https://icdn.tradew.com/file/201803/1572753/jpg/7589740.jpg?x-oss-process=image/quality,Q_90)
Harden® large-scale hydraulic drive primary
shredder is design for volume reduction of bulky waste and pre-treatment of
solid waste, features powerful and stable operation and low maintenance cost.
With functions of shearing, chopping, tearing and extrusion, the shredder can
easily process a variety of waste such as untreated household wastes (MSW), decoration
waste and industrial waste.
Harden® primary shredder can output relatively uniform materials, which is convenient for further processes of separation or recycling, so as to obtain valuable resources or high calorific value RDF.
Features of Harden® Primary Shredder TPH Series
![](https://icdn.tradew.com/file/201803/1572753/jpg/7432976.jpg?x-oss-process=image/quality,Q_90)
Fixed blade pedestal
Integral structure & reinforced knives
![](https://icdn.tradew.com/file/201803/1572753/jpg/7432977.jpg?x-oss-process=image/quality,Q_90)
Knives welding
Patented technology of welding gap protection
![](https://icdn.tradew.com/file/201803/1572753/jpg/7432978.jpg?x-oss-process=image/quality,Q_90)
Articulated arm
Unloads shaft torque &filters the impact
![](https://icdn.tradew.com/file/201803/1572753/jpg/7589751.jpg?x-oss-process=image/quality,Q_90)
Sealing performance
Integral axle sleeve sealing structure & anti-dust clearance
![](https://icdn.tradew.com/file/201803/1572753/png/7432991.png?x-oss-process=image/quality,Q_90)
High-performance Hydraulic System
Hydraulic constant power provides variable speed control
![](https://icdn.tradew.com/file/201803/1572753/jpg/7589757.jpg?x-oss-process=image/quality,Q_90)
Central lubrication
Operational friendly
Drawing
![](https://icdn.tradew.com/file/201803/1572753/png/7432993.png?x-oss-process=image/quality,Q_90)
TPH1026
![](https://icdn.tradew.com/file/201803/1572753/png/7432994.png?x-oss-process=image/quality,Q_90)
TPH1620/TPH1826
Parameters
Model |
TPH1026 | TPH1620 |
TPH1826 |
Motor Power (KW) |
132-200 | 132-250 |
250 |
Rotating Speed (RPM) |
17-58 | 17-58 |
17-58 |
Cutting Chamber (A*B)(mm) | 1000*2600 | 1600*2000 | 1900*2600 |
Overall Dimension (L*W*H)(mm) |
5000*1550*1200 | 4400*2100*1060 |
5020*2400*1242 |
Quantity of Blade (PCS) | 9/11 | 14/18 | 14/18 |
Capacity (Ton/Hour) | 15-40 | 20-50 | 30-80 |
Application
![](https://icdn.tradew.com/file/201803/1572753/png/7011137.png?x-oss-process=image/quality,Q_90)
MSW
![](https://icdn.tradew.com/file/201803/1572753/jpg/7011140.jpg?x-oss-process=image/quality,Q_90)
Commercial Waste
![](https://icdn.tradew.com/file/201803/1572753/jpg/7011139.jpg?x-oss-process=image/quality,Q_90)
Bulky Waste
![](https://icdn.tradew.com/file/201803/1572753/jpg/7011141.jpg?x-oss-process=image/quality,Q_90)
Organic Waste
![](https://icdn.tradew.com/file/201803/1572753/png/7011138.png?x-oss-process=image/quality,Q_90)
Decoration Waste
![](https://icdn.tradew.com/file/201803/1572753/jpg/7011146.jpg?x-oss-process=image/quality,Q_90)
Waste Car
![](https://icdn.tradew.com/file/201803/1572753/jpg/7011148.jpg?x-oss-process=image/quality,Q_90)
Waste Home Appliance
![](https://icdn.tradew.com/file/201803/1572753/jpg/7011150.jpg?x-oss-process=image/quality,Q_90)
Iron & Aluminum Scraps
Shredding result
![](https://icdn.tradew.com/file/201803/1572753/jpg/7733445.jpg?x-oss-process=image/quality,Q_90)
Selected cases
![](https://icdn.tradew.com/file/201803/1572753/jpg/7733426.jpg?x-oss-process=image/quality,Q_90)
For legacy waste
![](https://icdn.tradew.com/file/201803/1572753/jpg/7733427.jpg?x-oss-process=image/quality,Q_90)
For bulky waste
![](https://icdn.tradew.com/file/201803/1572753/jpg/7733428.jpg?x-oss-process=image/quality,Q_90)
For bulky waste
![](https://icdn.tradew.com/file/201803/1572753/jpg/7733429.jpg?x-oss-process=image/quality,Q_90)
For bulky waste
